Description

MB-280CSO-1MACC 220MM 240V SWIVEL HEAD BANDSAW INC STAND MB-280CSO-1

The bandsaw includes an incorporated recirculating coolant system and an adjustable material stop for repetitive production. Safety is ensured with an emergency stop switch, and the product comes with a 12-month warranty, stand, and blade. Specifications include a 1.5hp single-phase (240V) motor, weight of 230kg, blade size of 27mm x 0.9mm x 2450mm, and a blade speed of 64 meters per minute. MB-280CSO-1 cutting capacities are as follows: at 90°, it can cut round materials up to 220mm, square materials up to 215mm, and rectangular materials up to 250x155mm; at 45° left and right, it can cut round materials up to 160mm, square materials up to 150mm, and rectangular materials up to 160x110mm; and at 60° right, it can cut round materials up to 100mm, square materials up to 85mm, and rectangular materials up to 95x80mm.

Features

Italian made quality.
1-way swivel head enables from 0° to 60° mitre cuts.
Dual mode operation.
– Trigger switch with manual down feed for small quick cuts.
– Control panel with fully adjustable hydraulic down feed & automatic shut-off at end of cut, for cutting larger material.
Incorporated recirculating coolant system.
Adjustable material stop for repetitive production.
Safety emergency stop switch.
12 months warranty.
MB-280CSO-1 Comes complete with stand & blade.

Specifications for MB-280CSO-1

Motor: 1.5hp Single Phase (240V)
Weight: 230kg
Blade Size: 27mm x 0.9mm x 2450mm
Blade Speed: 1 Speed 64mpm
90° Cutting Capacity:
- Round: 220mm
- Square: 215mm
- Rectangle: 250x155mm
45° Left & Right Cutting Capacity:
- Round: 160mm
- Square: 150mm
- Rectangle: 160x110mm
60° Right Cutting Capacity:
- Round: 100mm
- Square: 85mm
- Rectangle: 95x80mm
